OptoTool

OptoTool is the innovative tool design-Software for your optical production made by OptoTech. Whether tool calculations, polishing foil calculations or workroom investigations with moving axes, OptoTool is the clever software for the complete range of complex tool design tasks.

PDF Download

Contact request

Highlights

Calculation of all tools needed to process spherical lenses
Support of all spherical OptoTech machines, tools and processes
Easy to upgrade to other machines, tools and processes
Display of all needed drawings and assembly drawings including polishing-foil-calculation
Easy changing of drawings due to parameter input
Allocation of multiple machines to one project. Hereby tools can be copied to other machines.
Workroom observation by axe moving In-workroom measurement
Default values of drawings e.g. tolerances, can be changed by configuration data
ITAR related drawings with special flag
Machines with up to 6 spindles can be illustrated
Easy handling by using shortcuts
Tools (drawings) of other CAD systems can be checked via interface in the workroom

Process characteristics

Interfaces:

DXF - Interface
ASCII Interface for data exchange with external programs
Import and export of calculated records

Options

Pellet calculation - To calculate a pellet layout for corresponding tools
OptoCAD - To modify OptoTool drawings and to create new machine workrooms and drawings for tool macros

Technical Data
